Honda Accord IX (2012-2016) front passenger power window switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger power window switch, which is found in the car Honda Accord IX (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger power window switch (1 of 1)
36 28 30 15 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER POWER WINDOW SWITCH
FUSE 13
FUSE BOX (LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
LEFT POWER MIRROR
LT BLU WIRE
LT GRN WIRE
NOISE REDUCTION CONDENSER
ORG/ WIRE
PNK REAR WINDOW DEFOGGER SWITCH INDICATOR WIRE
POWER WINDOW MASTER SWITCH (EXCEPT SPORT)
POWER WINDOWS SYSTEM
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH HVAC CONTROL UNIT/ CLIMATE CONTROL UNIT
RELAY ENERGIZED
RIGHT POWER MIRROR
UNDER-DASH FUSE/RELAY
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
Go to component -> Defoggers circuit, except hybrid -> FRONT PASSENGER POWER WINDOW SWITCH
