Honda Accord IX (2012-2016) engine mount control unit Wiring diagram
This page shows the only wiring diagram for the component.engine mount control unit, which is found in the car Honda Accord IX (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine mount control unit (1 of 1)
2.4L CVT, M/T
3.5L
A/T CVT
A/T, CVT 4 3 M/T
ANC/ ACTIVE SOUND CONTROL UNIT
BLK WIRE
CONSOLE ACCESSORY POWER SOCKET
DOOR UNLOCK UNLOCK RELAY RELAY
DRIVER'S SEAT HEATER SWITCH
ENGINE MOUNT CONTROL UNIT
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S SEAT HEATER SWITCH
LOCK RELAY
M/T
MICU
POWER TRANSISTOR
RIGHT FOG LIGHT
RIGHT FRONT TURN SIGNAL LIGHT/ SIDE MARKER LIGHT
RIGHT HEADLAMP (HIGH)
RIGHT INNER TAILGATE (LED)
RIGHT LEFT BACKUP BACKUP LIGHT LIGHT
SEDAN 1 2 COUPE
STEERING ANGLE SENSOR
TRUNK LID LATCH SWITCH/ TRUNK RELEASE ACTUATOR
TRUNK LID OUTER KEYLESS HANDLE BUZZER SWITCH
TRUNK LID RELEASE ACTUATOR RELAY
W/ SEAT HEATERS
WINDSHIELD WASHER MAIN RELAY MICU
Go to component -> Ground distribution circuit, except hybrid (4 of 4) -> ENGINE MOUNT CONTROL UNIT
