Honda Accord IX (2012-2016) dr control block power window master switch Wiring diagrams
This page contains all the electrical diagrams for the component. dr control block power window master switch, in which he is found in the car Honda Accord IX (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
dr control block power window master switch wiring diagram (1 of 2)
10 12 37 25 30 28 31 PPL
3.5L
A/T CVT
A/T GEAR POSITION INDICATOR PANEL LIGHT/ PARK-PIN SWITCH (A/T, CVT)
AMBIENT LIGHT
AUDIO REMOTE SWITCH
BLK WIRE
BLU WIRE
CABLE REEL (IN STEERING COLUMN)
CENTER JUNCTION BOX
CLIMATE CONTROL UNIT/HVAC CONTROL UNIT
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL COMBINATION/
DR CONTROL BLOCK POWER WINDOW MASTER SWITCH
DRIVER'S JUNCTION BOX (EXCEPT 2.4L M/T W/O NAVIGATION)
DRIVER'S POSITION MEMORY SWITCH (W/ MEMORY)
DRIVER'S SEAT HEATER SWITCH (IF EQUIPPED)
ECON SWITCH
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HFL/ HFL- NAVIGATION VOICE CONTROL SWITCH
HOMELINK UNIT (W/ NAVIGATION) (IN ROOF CONSOLE)
IND 1
IND 2
LDW OFF SWITCH (W/ NAVIGATION)
LEFT REAR POWER WINDOW SWITCH (SEDAN)
LIGHTS IND
LT GRN WIRE
MOONROOF SWITCH
MULTI INFORMATION DISPLAY UNIT
MULTI- INFORMATION DISPLAY SWITCH (3.5L A/T)
ORG/ WIRE
PNK WIRE
POWER MIRROR SWITCH
PPL
RED WIRE
RIGHT REAR POWER WINDOW SWITCH (SEDAN)
VSA OFF SWITCH
W/ MOONROOF
W/ MOONROOF W/O MOONROOF
W/ SEAT HEATERS, NAVIGATION
Go to component -> Instrument illumination circuit, except hybrid (2 of 2) -> DR CONTROL BLOCK POWER WINDOW MASTER SWITCH
dr control block power window master switch wiring diagram (2 of 2)
10 12 37 25 30 28 31 PPL
AS IND
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX
CHARGE LID OPENER SWITCH (IF EQUIPPED)
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DR CONTROL BLOCK POWER WINDOW MASTER SWITCH
ECON SWITCH
EV SWITCH
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUEL FILL DOOR OPENER SWITCH (IF EQUIPPED)
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HV SWITCH
IND 1 DRIVING POSITION MEMORY SWITCH (IF EQUIPPED)
IND 2
LDW OFF SWITCH
LEFT REAR POWER WINDOW SWITCH
LT GRN WIRE
ORG/ WIRE
PLUG-IN HYBRID EXCEPT PLUG-IN HYBRID
PNK WIRE
POWER MIRROR SWITCH
PPL
RED WIRE
RIGHT REAR POWER WINDOW SWITCH
VSA OFF SWITCH
Go to component -> Instrument illumination circuit, hybrid (3 of 3) -> DR CONTROL BLOCK POWER WINDOW MASTER SWITCH
