Honda Accord IX (2012-2016) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Honda Accord IX (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram blk (151 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (151 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

22 23 PNK WIRE 5 6 7 8 9 PPL AUDIO/AUDIO- NAVIGATION UNIT AUXILIARY JACK BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM F-CAN F-CAN F-CAN TRANSCEIVER FM DISTRIBUTION FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE (IN ROOF CONSOLE) GAUGE CONTROL MODULE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NCA WIRE PNK 13 14 WIRE PNK PPL WIRE PNK WIRE PPL RED WIRE ROOF ANTENNA SUB AMPLIFIER WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid (4 of 5) -> BLK WIRE

Wiring diagram blk (152 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (152 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

1 PIN CONNECTOR 14 PIN CONNECTOR 22 23 PNK WIRE 32 24 16 32 PIN CONNECTOR 4 1 3 2 5 5 PIN CONNECTOR AUDIO/AUDIO- NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (RIGHT END OF DASH) LT BLU WIRE LT GRN WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE PNK 13 14 WIRE PNK PPL WIRE PNK WIRE PPL RED WIRE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid (5 of 5) -> BLK WIRE

Wiring diagram blk (153 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (153 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

16 17 PNK WIRE AUDIO REMOTE SWITCH AUDIO- NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) CENTER JUNCTION BOX CH+ SWITCH COMPUTER DATA LINES SYSTEM DISP SWITCH FUSE FUSE 21 FUSE 22 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE PPL PPL PPL RED WIRE SOURCE SWITCH UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) USB PORT VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Go to component -> Navigation circuit, plug-in hybrid (1 of 6) -> BLK WIRE

Wiring diagram blk (154 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (154 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

10 11 PPL 16 17 PNK WIRE AUDIO- NAVIGATION UNIT B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DC-DC CONVERTER DRIVER'S JUNCTION BOX F-CAN H F-CAN L F-CAN TRANSCEIVER GAUGE CONTROL MODULE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NAVIGATION SWITCH PANEL ORG/ WIRE PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY) PCM (LEFT FRONT OF ENGINE COMPT) PNK WIRE POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER PPL PPL PPL RED WIRE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, plug-in hybrid (2 of 6) -> BLK WIRE

Wiring diagram blk (155 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (155 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

10 11 PPL 7 8 9 PNK WIRE AM/FM/ TEL/GPS ANTENNA BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE LEFT REAR DOOR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT REAR DOOR SPEAKER RIGHT TWEETER SUB AMPLIFIER WHT WIRE YEL WIRE

Go to component -> Navigation circuit, plug-in hybrid (3 of 6) -> BLK WIRE

Wiring diagram blk (156 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (156 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

6 7 8 PNK WIRE 7 8 9 PNK WIRE ANC/ACTIVE SOUND CONTROL UNIT (CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX FRONT HFL- NAVIGATION-ANC/ ACTIVE SOUND CONTROL MICROPHONE (IN ROOF CONSOLE) FUSE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE MICU PNK WIRE PPL REAR ANC/ACTIVE SOUND CONTROL MICROPHONE (CENTER REAR OF ROOF) RED WIRE RELAY ENERGIZED UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Go to component -> Navigation circuit, plug-in hybrid (4 of 6) -> BLK WIRE

Wiring diagram blk (157 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (157 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

6 7 8 PNK WIRE AUDIO- NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL PPL 1 2 RED WIRE TELEMATICS CONTROL UNIT (RIGHT END OF DASH) WHT WIRE YEL WIRE

Go to component -> Navigation circuit, plug-in hybrid (5 of 6) -> BLK WIRE

Wiring diagram blk (158 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (158 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO- NAVIGATION UNIT AUXILIARY JACK BLK WIRE BRN WIRE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE PNK WIRE PPL PPL 1 2 REARVIEW CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE RIGHT POWER MIRROR WHT WIRE YEL WIRE

Go to component -> Navigation circuit, plug-in hybrid (6 of 6) -> BLK WIRE

Wiring diagram blk (159 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (159 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 22 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE PNK WIRE PPL REARVIEW CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE

Go to component -> Rear camera circuit, except hybrid coupe -> BLK WIRE

Wiring diagram blk (160 of 263)

Wiring diagram blk for Honda Accord IX (2012-2016) (160 of 263)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM EXCEPT SPORT FUSE 22 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE PNK WIRE PPL REARVIEW CAMERA REARVIEW CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE SPORT UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE

Go to component -> Rear camera circuit, except hybrid sedan -> BLK WIRE
