Headlights circuit for GMC Yukon V (2020-2024)

AMBIENT LIGHT SENSOR SIGNAL AUTO BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) BODY CONTROL MODULE LIN BUS 6 COMPUTER DATA LINES SYSTEM DIMMER SWITCH DRIVER INFORMATION CENTER DISPLAY DRL IND ENGINE WIRING HARNESS JUNCTION BLOCK FOG LAMP IND FRONT FOG LAMP SWITCH GRN/BLK WIRE GRN/BRN WIRE GRN/VIO WIRE HEAD HEADLAMP SWITCH HEADLAMP SWITCH FLASH SIGNAL HEADLAMP SWITCH OFF SIGNAL HEADLAMP SWITCH ON SIGNAL HEADLAMP SWITCH REFERENCE HEADLAMP SWITCH SIGNAL HIGH BEAM LAMP IND HIGH BEAM SELECT SWITCH HIGH BEAM SIGNAL HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE LIN BUS 1 LOGIC OFF PARK REAR FOG LAMP SWITCH RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE SENSOR LOW REFERENCE TURN SIGNAL SWITCH WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BRN WIRE

BLK WIRE BLK/YEL WIRE BLU/BRN WIRE GRY/BLU WIRE HEADLAMP COOLING FAN HIGH BEAM HOT AT ALL TIMES LEFT FRONT HEADLAMP LEFT HEADLAMP LED DRIVER MODULE LOGIC LOW BEAM MULTI-FUNCTION POWER SUPPLY CONVERTER POWER DISTRIBUTION RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT END OF DASH) RIGHT FRONT HEADLAMP RIGHT HEADLAMP LED DRIVER MODULE RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK SYSTEM WHT WIRE WHT/BLU WIRE YEL WIRE

AIR CONDITIONING SYSTEM AUTOSAR CAN BUS (+) 2 SERIAL DATA BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/YEL WIRE BRN/GRN WIRE BRN/GRY WIRE CHEVROLET COMPUTER DATA LINES SYSTEM GMC GRN/YEL WIRE GRY/BLU WIRE LEFT FRONT DRL CTRL LEFT FRONT FOG LAMP LEFT FRONT FOG LAMP CTRL LEFT HEADLAMP HIGH BEAM CTRL LEFT REAR FASCIA LOWER SIGNAL LAMP LIGHTING CONTROL MODULE LOGIC LT HEADLAMP LO BEAM CTRL PARK BRAKE SWITCH PARKING BRAKE CONTROL SWITCH REAR FOG LAMP CTRL RED/BRN WIRE RED/GRN WIRE RIGHT FRONT DRL CTRL RIGHT FRONT FOG LAMP RIGHT FRONT FOG LAMP CTRL RIGHT HEADLAMP HIGH BEAM CTRL RIGHT REAR FASCIA LOWER SIGNAL LAMP RT HEADLAMP LO BEAM CTRL SUNLOAD, AMBIENT LIGHT, SECURITY INDICATOR SENSOR WHT WIRE WHT/BLU WIRE YEL WIRE YEL/GRY WIRE
