Car Wiring Diagrams for Chime circuit for GMC Yukon II (1999-2006)

ANL/DRL DEFEAT AUTO BATTERY BATTERY BATTERY BATTERY GROUND BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) FUSE GROUND DISTRIBUTION SYSTEM GRY WIRE GRY/BLK WIRE HEAD PARK HEADLAMP DIMMER SWITCH HEADLAMP SWITCH HOT AT ALL TIMES HOT IN ACC, RUN HOT IN ACC, RUN, START HOT IN RUN, START I/P RELAY BLOCK (UNDER LEFT SIDE OF DASH, NEAR KICK PANEL) IGNITION KEY ALARM SWITCH LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LEFT REAR MINI-WEDGE DOOR JAMB SWITCH LIFTGATE AJAR SWITCH SIG RIGHT REAR DOOR AJAR SW LEFT REAR DOOR AJAR SW LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PARK BRAKE SWITCH (PART OF PARK BRAKE ASSEMBLY) PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RIGHT REAR MINI-WEDGE DOOR JAMB SWITCH SERIAL DATA SERIAL DATA PARK LAMP ON SIGNAL GROUND DIMMING INPUT TBC ACCY FUSE TBC BATT FUSE TBC IGN 0 FUSE TBC IGN 1 FUSE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPARTMENT, NEAR BATTERY) WHT WIRE YEL WIRE

22 3 11 SERIAL DATA LEFT SEAT BELT SW LOW REFERENCE 22 3 18 SERIAL DATA LOW REFERENCE LEFT DOOR AJAR SW 22 5 20 SERIAL DATA DOOR AJAR SWITCH LOW REFERENCE 59 58 SERIAL DATA SERIAL DATA BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRIVER DOOR MODULE (DDM) (IN DRIVER'S DOOR) DRIVER MINI-WEDGE DOOR JAMB SWITCH DRIVER SEAT BELT SWITCH FRONT PASSENGER DOOR MODULE (FPDM) (IN RIGHT FRONT DOOR) GRY WIRE GRY/BLK WIRE IGN INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER LEFT FRONT SEAT) INSTRUMENT PANEL CLUSTER (IPC) LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH) LEFT LIFTGATE AJAR SWITCH LEFT TURN LIFTGLASS AJAR SWITCH LOGIC LT BLU WIRE LT GRN WIRE ORG/ WIRE PASSENGER MINI WEDGE (DOOR JAMB SWITCH) PNK PNK WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) (AT LEFT FRONT OF ENGINE COMPARTMENT) PPL PPL PPL 1132 1807 RADIO RIGHT CARGO DOOR AJAR SWITCH RIGHT DOOR CONTACT PLATE (BODY) RIGHT DOOR CONTACT PLATE (DOOR) RIGHT I/P FUSE BLOCK (ON LOWER RIGHT SIDE OF DASH) RIGHT LIFTGATE AJAR SWITCH RIGHT TURN SEAT BELT SERIAL DATA SPLICE PACK SUPPLEMENTAL RESTRAINTS SYSTEM TAN WIRE W/ANTI-THEFT SYSTEM 1036 1044 1045 W/CARGO DOORS W/O CARGO DOORS WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE
