Car Wiring Diagrams for Adjustable pedal circuit for GMC Yukon II (1999-2006)

1 7 BATT (+) GND BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA ADJUST PDL SENSOR SIG COMPUTER DATA LINES SYSTEM DRIVER BACK HEATED SEAT ELEMENT DRIVER DOOR MODULE DRIVER SEAT RECLINER MOTOR POSITION SENSOR EAP FUSE ELECTRONIC ADJUSTABLE PEDALS ASSEMBLY ELECTRONIC ADJUSTABLE PEDALS RELAY (BEHIND LOWER LEFT OF DASH) ELECTRONIC ADJUSTABLE PEDALS SWITCHES EXIT FRONT PASS- ENGER BACK HEATED SEAT ELEMENT HOT AT ALL TIMES I/P RELAY BLOCK (LEFT OF STEERING COLUMN) LOW REF LT BLU WIRE MEMORY SEAT MODULE (UNDER LEFT FRONT SEAT) MEMORY/ HEATED SEAT SWITCH ORG/ WIRE ORG/BLK WIRE PNK (IN DRIVER SEAT JUMPER HARN) WIRE PNK WIRE PPL RECLINE MTR POS SEN SIG RED WIRE SEAT CIRCUIT BREAKER SET 1 SET 2 TAN WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE
