Car Wiring Diagrams for Headlights circuit for GMC Yukon II (1999-2006)

AMBIENT LIGHT SENSOR (ON TOP CENTER OF DASH) AMBIENT LT SENS DRL SW SIG FOG LP SW SIG HDLP DIM SW SIG ANL/DRL DEFEAT AUTO AUTO PARK HEAD BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRL FUSE DRL RELAY FLASH TO PASS FOG LAMP SWITCH FOG LP FUSE FOG LP RELAY HDLP HI BM RELAY HDLP LO BM RELAY HEADLAMP SWITCH HI BM RLY CTRL LO BM RLY CTRL DRL RLY CTRL FOG LP RLY CTRL HI HDLP LT FUSE HI HDLP RT FUSE HI/LO BEAM SELECT HLPS ON SIG FLASH TO PASS PK BRAKE SIG LOW REF HOT AT ALL TIMES I/P RELAY BLOCK LEFT DAYTIME RUNNING LAMP, LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP LEFT HIGH BEAM HEAD- LAMP LEFT LOW BEAM HEAD- LAMP LO HDLP LT FUSE LO HDLP RT FUSE LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MULTIFUNCTION ACCESSORY SWITCH ORG/ WIRE PARK BRAKE SWITCH (PART OF PARK BRAKE ASSEMBLY) PNK WIRE PNK/WHT WIRE PPL RIGHT DAYTIME RUNNING LAMP RIGHT HIGH BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP TAN WIRE TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE
