GMC Yukon II (1999-2006) high indicator control low indicator control Wiring diagram
This page shows the only wiring diagram for the component.high indicator control low indicator control, which is found in the car GMC Yukon II (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high indicator control low indicator control (1 of 1)
BATTERY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
FUSE
GROUND
HIGH HEAT
HIGH INDICATOR CONTROL
HIGH INDICATOR CONTROL LOW INDICATOR CONTROL
HOT AT ALL TIMES
HOT IN RUN
HTD CSHN ELEMENT CTRL
HTD CSHN ELEMENT CTRL LOW REF
HTD CSHN TEMP SENS
I/P RELAY BLOCK
IGN 3
IGN 3 FUSE
LEFT I/P FUSE BLOCK
LEFT REAR HEATED SEAT ELEMENT
LEFT REAR HEATED SEAT MODULE
LEFT REAR HEATED SEAT SWITCH
LOW HEAT
LOW INDICATOR CONTROL
LOW REF
MODE
NCA WIRE
ORG/ WIRE
PNK WIRE
PTC THERMISTOR
RED/WHT WIRE
RIGHT REAR HEATED SEAT ELEMENT
RIGHT REAR HEATED SEAT MODULE
RIGHT REAR HEATED SEAT SWITCH
SIGNAL
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> Rear heated seats circuit -> HIGH INDICATOR CONTROL LOW INDICATOR CONTROL
