Supplemental restraint circuit for GMC Vandura Special G3500 (1985-1996)

1 2 3 4 PASS SIDE HIGH INFL OUT DRIV INFL FEED DRIV INFL OUT PASS 5 6 DATA LINE SIR GROUND 8 9 10 11 12 SEAT BELT SIG SIR FWD SENS IGN 1 AIR BAG INDICATOR AIR BAGS FUSE 10 AIR BAGS FUSE 4 BLK WIRE BLK/WHT WIRE BRN WIRE DATA LINK CONNECTOR (LEFT I/P) DK GRN WIRE DK GRN/WHT WIRE GRN/WHT WIRE GRY WIRE HOT IN RUN OR START I/P FUSE BLOCK INFLATABLE RESTRAINT CONTROL MODULE (BELOW LEFT FRONT SEAT) INFLATABLE RESTRAINT FRONT END DISCRIMINATING SENSOR (FRONT OF VEHICLE) INFLATABLE RESTRAINT I/P MODULE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL SHORTING BAR INFLATABLE RESTRAINT STEERING WHEEL MODULE SHORTING BAR INSTRUMENT CLUSTER LF SEAT BELT INPUT MULTI-FUNCTION ALARM MODULE NCA WIRE PNK WIRE SEAT BELT SWITCH (IN DRIVER'S BELT BUCKLE) SHORTING BAR SHORTING BAR 358 238 349 1139 TAN WIRE WHT WIRE YEL WIRE
