5.7l (vin r), transmission circuit, 4l80-e for GMC Vandura P3500 (1985-1997)

1-2 SHIFT SOL 1-2 SHIFT SOLENOID 2-3 SHIFT SOL 2-3 SHIFT SOLENOID A/T INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) A/T ISS HI IN A/T ISS LO IN ACCESSORY POWER POINT AUTOMATIC TRANSMISSION BATTERY IN BLK WIRE BLK/WHT WIRE BRAKE SWITCH INPUT BRN WIRE BRN/WHT WIRE DASH FUSE BLOCK TRANS FUSE DATA CLASS II DK BLU WIRE DK BLU/WHT WIRE ECM BATT FUSE ECM I FUSE ECT SENS INPUT ELECTRONIC BRAKE CONTROL MODULE ENG 1 FUSE ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE) FUEL INJECTORS (ENIGINE CONTROLS SYSYTEM) FUEL PUMP RELAY, FUEL PUMP SWITCH/ENGINE OIL PRESSURE GAUGE SENSOR GAUGES FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START I-3 FUSE IGNITION IN INSTRUMENT CLUSTER LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MIL CONTROL ORG/ WIRE PCM GROUND PCS SOL HI OUT PCS SOL LO OUT PNK WIRE PPL PPL DATA LINK CONNECTOR (PARTIAL) (BELOW DASH NEAR STEERING COLUMN) PPL/WHT WIRE PRESS CTRL SOLENOID RANGE SIGNAL "A" RANGE SIGNAL "B" RANGE SIGNAL "C" RED WIRE RED/BLK WIRE SENSOR GROUND SENSOR RETURN SERVICE ENGINE SOON INDICATOR TCC PWM SOL TCC PWM SOLENOID TCC/STOP- LAMP SWITCH (ON BRAKE PEDAL BRACKET) THROTTLE POSITION SENSOR (MOUNTED TO SIDE OF THROTTLE BODY) TP SENS INPUT TRANS FLUID TEMP SENSOR TRANS RANGE PRESSURE SWITCH ASSEMBLY TRANS TEMP SIG IN VEHICLE CONTROL MODULE (LEFT FRONT CORNER OF ENGINE COMPT) VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION) VSS HI VSS LO VSS SENSOR SHIELD YEL WIRE YEL/BLK WIRE
