Wiring diagram engine performance 7.4l (vin n)s, a/t p/g cutaway (1 of 3) for GMC Vandura P3500 (1985-1997)

5.7L 7.4L 7.4L ONLY AIR CONDITION- ING SYSTEM BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE DIAGNOSTIC TEST TP SENSOR SIGNAL INJECTOR 1 CONTROL DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE ECM BAT FUSE ECM I FUSE ECT SIGNAL EGR CONTROL EVAPORATIVE CANISTER PURGE CONTROL SOLENOID (TOP RIGHT SIDE OF ENGINE) EXHAUST GAS RECIRCULATION VALVE SOLENOID (TOP RIGHT SIDE OF ENGINE) FUEL PUMP RELAY CTRL PCS LOW FUEL PUMP SIGNAL MAP SIGNAL FUSE BLOCK GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START IC BYPASS SENSOR GROUND SENSOR GROUND TFT SIGNAL 470 455 PPL IDLE AIR CONTROL ACTUATOR (TOP REAR OF ENGINE) IDLE SPEED ACTUATOR CONTROL SOLENOID (NO LOCATION AVAILABLE) KNOCK SIGNAL EGR PINTLE POSITION SIGNAL LINEAR EGR VACUUM REGULATOR SOLENOID VALVE (TOP FRONT OF ENGINE) LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE NCA WIRE ORG/ WIRE OXYGEN SENSOR (IN EXHAUST MANIFOLD) OXYGEN SENSOR GROUND PNK 22 23 WIRE PNK RANGE SIGNAL A INPUT SPEED SIGNAL HIGH INPUT SPEED SIGNAL LOW WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (LEFT SIDE OF SHIPPING PANEL) PPL PPL 20 21 PPL/WHT WIRE RANGE SIGNAL B RANGE SIGNAL C MIL CONTROL RED WIRE RED/BLK WIRE TAN WIRE TAN/BLK WIRE TAN/WHT WIRE THROTTLE BODY FUEL INJECTOR #1 (TOP OF THROTTLE BODY UNIT) THROTTLE BODY FUEL INJECTOR #2 (TOP OF THROTTLE BODY UNIT) TRANSMISSION INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
