6.5l (vin y), a/c circuit for GMC Vandura P3500 (1985-1997)
6.5l (vin y), a/c circuit
A/C COMPRESSOR CLUTCH RELAY (ENGINE BULKHEAD RELAY BRACKET)
A/C COMPRESSOR HIGH PRESSURE CUTOFF SWITCH (REAR OF COMPRESSOR)
A/C COMPRESSOR REFRIGERANT PRESSURE SWITCH (REAR OF COMPRESSOR)
AUXILIARY ENGINE COOLANT FAN
AUXILIARY ENGINE COOLANT FAN A/C PRESSURE SWITCH (IN A/C HIGH PRESSURE LINE)
AUXILIARY ENGINE COOLANT FAN RELAY (ENGINE BULKHEAD RELAY BRACKET)
AUXILIARY FAN CONTROL SWITCH (RIGHT SIDE OF CYLINDER HEAD)
BLK WIRE
BRN WIRE
DIODE A/C COMPRESSOR CLUTCH
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
FUSIBLE LINK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN ENG 1 FUSE
I/P FUSE BOX
ORG/ WIRE
PNK WIRE
RED WIRE
VIN N ONLY
