GMC Vandura P3500 (1985-1997) trans- mission range indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.trans- mission range indicator lamp, which is found in the car GMC Vandura P3500 (1985-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans- mission range indicator lamp (1 of 1)
BLK WIRE
BRN WIRE
DIM HIGH
DK GRN WIRE
DOME LAMP SWITCH
GRY WIRE
HEADLAMPS SWITCH
HORN DIMMER FUSE
HOT AT ALL TIMES
HOT WITH PARK OR HEADLAMP SWITCH ON
I/P FUSE BLOCK
INSTR LPS FUSE
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMER SWITCH
LIGHT SWITCH
OFF HEAD PARK
ORG/ WIRE
PANEL LAMPS SWITCH
PROVISION FOR DOME LAMP
PROVISION FOR ROOF MARKER LAMPS
TAIL LPS FUSE
TRANS- MISSION RANGE INDICATOR LAMP
WHT WIRE
Go to component -> Interior light circuit, motor home chassis -> TRANS- MISSION RANGE INDICATOR LAMP
