GMC Vandura P3500 (1985-1997) ref lo temp Wiring diagrams
This page contains all the electrical diagrams for the component. ref lo temp, in which he is found in the car GMC Vandura P3500 (1985-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ref lo temp (1 of 2)
A/C COMPRESSOR HIGH PRESSURE CUT-OFF SWITCH (REAR OF A/C COMPRESSOR)
A/T
BLK WIRE
BREAKOUT)
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
FROM ECT SENSOR BREAKOUT)
FROM TPS BREAKOUT)
FUEL GAUGE
FUEL PUMP SWITCH, ENGINE OIL PRESSURE GAUGE SENSOR (TOP LEFT REAR OF ENGINE)
FUEL SENDER, FUEL PUMP (TOP OF FUEL TANK)
GAUGES FUSE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN (ON) RUN, START (CRANK)
I/P FUSE BLOCK (DASH PANEL PROVIDED BY BODY BUILDER) (BODY BUILDER INSTALLED)
INSTRUMENT CLUSTER
LT BLU/WHT WIRE
LT GRN WIRE
M/T
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (INTAKE MANIFOLD, REAR CENTER)
MAP REF LO
MASS AIR FLOW SENSOR (MAF) (AIR INTAKE SYSTEM BETWEEN AIR CLEANER, ENGINE)
NCA WIRE
OIL PRESS GAUGE
ORG/ WIRE
PNK PNK 2 3 4 5 6 7 8 9 WIRE
PNK PNK PNK 2 3 4 5 WIRE
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
REF LO TEMP
REF THROTTLE POSITION (TP) SENSOR (INTAKE SYSTEM, LEFT SIDE)
SENSOR BREAKOUT)
SERVICE ENGINE SOON INDICATOR
SPEEDO- METER
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 4.3l (vin w)s, commercial chassis (3 of 4) -> REF LO TEMP
Wiring diagram ref lo temp (2 of 2)
A/C COMPRESSOR HIGH PRESSURE CUT-OFF SWITCH (REAR OF A/C COMPRESSOR)
BLK WIRE
BREAKOUT)
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG-BAT FUSE
FROM ECT SENSOR BREAKOUT)
FROM MAF SENSOR BREAKOUT)
FROM TP SENSOR BREAKOUT)
FUEL PUMP SWITCH, ENGINE OIL PRESSURE GAUGE SENSOR (TOP LEFT REAR OF ENGINE)
FUEL SENDER, FUEL PUMP (TOP OF FUEL TANK)
GAUGES FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN (ON) RUN, START (CRANK)
I/P FUSE BLOCK (DASH PANEL PROVIDED BY BODY BUILDER) (BODY BUILDER INSTALLED)
INSTRUMENT CLUSTER
LT BLU/WHT WIRE
LT GRN WIRE
M/T A/T
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (INTAKE MANIFOLD, REAR CENTER)
MAP
MASS AIR FLOW (MAF) SENSOR (AIR INTAKE SYSTEM BETWEEN AIR CLEANER, ENGINE)
NCA WIRE
OIL PRESS GAUGE FUEL GAUGE
ORG/ WIRE
PNK 5 6 7 WIRE
PNK PNK PNK PNK 1 2 3 4 WIRE
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
REF LO
REF LO TEMP
REF THROTTLE POSITION (TP) SENSOR (INTAKE SYSTEM, LEFT SIDE)
SERVICE ENGINE SOON INDICATOR
SPEEDO- METER
TAN WIRE
TRANS FUSE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.7l (vin r)s, commercial chassis (3 of 4) -> REF LO TEMP
