GMC Vandura P3500 (1985-1997) automatic transmission shift interlock control relay Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission shift interlock control relay, which is found in the car GMC Vandura P3500 (1985-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission shift interlock control relay (1 of 1)
6.5L VIN F
7.4L VIN N (L19), 7.4L
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CONTROL RELAY (7.4L VIN N
A/C COMPRESSOR RELAY
AUTOMATIC TRANSMISSION SHIFT INTERLOCK CONTROL RELAY
AUTOMATIC TRANSMISSION SHIFT INTERLOCK CONTROL SOLENOID
AUXILIARY ENGINE COOLANT FAN A/C PRESSURE SWITCH
BLK WIRE
CANADIAN MODELS ONLY
DATA LINK CONNECTOR (DLC) (7.4L VIN J (L29), 6.5L
DAYTIME RUNNING LAMP CONTROL MODULE (DRL)
DAYTIME RUNNING LAMP RELAY (DRL)
DK GRN WIRE
ENGINE COOLANT FAN MOTOR
ENGINE COOLANT LEVEL (ECL) SWITCH (6.5L VIN F
ENGINES
FUEL HEATER
FUEL LIFT PUMP
FUEL PUMP
FUEL SENDER
GALLON
GLOW PLUG RELAY
HEATED OXYGEN SENSOR LEFT POST CONVERTER
HEATED OXYGEN SENSOR LEFT PRE CONVERTER
HEATED OXYGEN SENSOR RIGHT POST CONVERTER
HEATED OXYGEN SENSOR RIGHT PRE CONVERTER
I/P FUSE BLOCK
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMER SWITCH
LEFT SIDE MARKER LAMP (PROVISIONS FOR)
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
RIGHT SIDE MARKER LAMP (PROVISIONS FOR)
SEATBELTS AND LAMP MODULE
SENDER
STARTER RELAY
STEERING COLUMN GROUND
TRANSMISSION RANGE INDICATOR LAMP
WATER IN FUEL INDICATOR SENSOR
Go to component -> Ground distribution circuit, motor home chassis (2 of 2) -> AUTOMATIC TRANSMISSION SHIFT INTERLOCK CONTROL RELAY
