GMC Vandura P3500 (1985-1997) 396 817 cruise status vehicle speed input Wiring diagram
This page shows the only wiring diagram for the component.396 817 cruise status vehicle speed input, which is found in the car GMC Vandura P3500 (1985-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 396 817 cruise status vehicle speed input (1 of 1)
396 817 CRUISE STATUS VEHICLE SPEED INPUT
4000 PULSES/MILE CRUISE STATUS
BLK WIRE
BLU WIRE
BRN WIRE
CRUISE CONTROL MODULE (RADIATOR SUPPORT BRACKET)
CRUISE CONTROL SWITCH
CRUISE ON INPUT SET/COAST INPUT RESUME/ACCEL INPUT
DK BLU WIRE
DK GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HAZARD LAMPS FLASHER
HOT AT ALL TIMES
HOT IN RUN
I-3 FUSE 9
I/P FUSE BLOCK
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
NCA WIRE
OFF
ORG/ WIRE
PPL
PPL DISENGAGE INPUT GROUND IGNITION BRAKE APPLIED INPUT
PPL/WHT WIRE
R/A
S/C
STOP/HAZ FUSE 11
STOPLAMP SWITCH (TOP OF BRAKE PEDAL)
VEHICLE CONTROL MODULE (VCM) (TOP OF RADIATOR SUPPORT)
VEHICLE SPEED SENSOR (VSS)
VSS RETURN
VSS SIGNAL
