6.5l (vin p), transmission circuit for GMC Vandura G2500 (1985-1995)

1-2 SHIFT SOL TCC SOL 2-3 SHIFT SOL ACCELERATOR PEDAL POSITION (APP) MODULE (TOP OF ACCEL- ERATOR BRACKET) APP #3 APP #3 SENSOR SIG APP 1 APP 2 BATTERY JUNCTION BLOCK BLK PNK/ WIRE BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE ECM 1 FUSE ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF LEFT CYLINDER HEAD) FUSIBLE LINK (20 GA- GAUGES FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK IGNITION FEED 3-2 CONTROL SOL DIAGNOSTIC REQUEST INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (RIGHT KICK PANEL) PPL PPL TCC/BRAKE SW PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SERVICE ENGINE SOON INDIC SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) TAN WIRE TAN/BLK WIRE TCC/STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) TRANS FLUID TEMP (TFT) SENSOR 3-2 SHIFT SOL TRANS FUSE 20 TRANSMISSION VEHICLE SPEED SENSOR BUFFER (PARKING BRAKE SUPPORT BRACKET) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
