Car Wiring Diagrams for Cooling fan circuit for GMC Vandura G2500 (1985-1995)

AUXILIARY COOLING FAN AUXILIARY COOLING FAN PRESSURE SWITCH (RIGHT SIDE OF ENGINE) AUXILIARY COOLING FAN RELAY (TOP LEFT SIDE OF SHIPPING PANEL) AUXILIARY COOLING FAN TEMPERATURE SWITCH (RIGHT SIDE OF ENGINE) BLK WIRE BLK/RED WIRE DK GRN WIRE FUSE BLOCK GAUGES FUSE HOT AT ALL TIMES FUSIBLE LINK HOT IN RUN PNK/WHT WIRE RED WIRE
