GMC Vandura G2500 (1985-1995) panel dimmer switch assembly dome switch Wiring diagram
This page shows the only wiring diagram for the component.panel dimmer switch assembly dome switch, which is found in the car GMC Vandura G2500 (1985-1995). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panel dimmer switch assembly dome switch (1 of 1)
BLK WIRE
BRN WIRE
DK GRN WIRE
DOME LAMP
FUSE BLOCK
GRY WIRE
HEADLIGHT SWITCH ASSEMBLY
HIGH DIM
HORN/DM FUSE
HOT AT ALL TIMES
I/P LPS FUSE
INSTRUMENT CLUSTER
LIGHT SWITCH
OFF HEAD PARK
ORG/ WIRE
PANEL DIMMER SWITCH (ASSEMBLY)
PANEL DIMMER SWITCH ASSEMBLY DOME SWITCH
TAIL LPS FUSE
TRANSMISSION RANGE INDICATOR LAMP
WHT WIRE
Go to component -> Interior light circuit, motorhome chassis -> PANEL DIMMER SWITCH ASSEMBLY DOME SWITCH
