Wiring diagram engine performance 5.7l (vin k)s, a/t p/g cutaway (3 of 3) for GMC Vandura G1500 (1985-1995)

1-2 SHIFT SOLENIOD 2-3 SHIFT SOLENIOD B/H CONN BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE DATA LINK CONNECTOR (BEHIND LEFT SIDE OF SHIPPING PANEL) DK BLU WIRE DK GRN/WHT WIRE ELECTRONIC 4-SPEED AUTOMATIC OVERDRIVE TRANSMISSION FUEL PUMP AND SENDER (IN FUEL TANK) FUEL PUMP FUSE FUEL PUMP OIL PRESSURE SWITCH (TOP REAR OF ENGINE) FUEL PUMP PRIME CONNECTOR (TOP OF COWL) FUEL PUMP RELAY (LOWER LEFT SIDE OF SHIPPING PANEL) FUSE BLOCK GRY WIRE HOT AT ALL TIMES LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE PPL PPL 3 4 PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SOLENOID TAN/BLK WIRE TORQUE CONVERTER CLUTCH TRANS- MISSION TEMP SENSOR VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (BEHIND RIGHT SIDE OF I/P) WHT/BLK WIRE YEL/BLK WIRE
