GMC Vandura G1500 (1985-1995) instrument cluster fasten belts indicator Wiring diagram
This page shows the only wiring diagram for the component.instrument cluster fasten belts indicator, which is found in the car GMC Vandura G1500 (1985-1995). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument cluster fasten belts indicator (1 of 1)
1995 VFTC
AUDIO ALARM MODULE
BATTERY INPUT GROUND
BLK WIRE
FUSE BLOCK
GAGES FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT WITH HEADLIGHT SWITCH IN PARK OR HEAD
IGN ON INPUT
INST LPS FUSE
INSTRUMENT CLUSTER FASTEN BELTS INDICATOR
KEY-IN WARNING BUZZER SWITCH
LEFT DOOR JAMB SWITCH
LIGHTS ON INPUT SAFETY BELT INPUT
LT GRN WIRE
ORG/ WIRE
PNK/BLK WIRE
SAFETY BELT BUCKLE SWITCH
SAFETY BELT INPUT FASTEN BELTS OUT
STOP- HZ FUSE
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> INSTRUMENT CLUSTER FASTEN BELTS INDICATOR
