GMC Vandura G1500 (1985-1995) engine controls system ppl Wiring diagram
This page shows the only wiring diagram for the component.engine controls system ppl, which is found in the car GMC Vandura G1500 (1985-1995). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls system ppl (1 of 1)
BACKUP LAMP SWITCH (ON STEERING COLUMN)
BLK WIRE
BRAKE SHIFT INTERLOCK RELAY (ON STEERING COLUMN)
BRAKE/TRANSMISSION SHIFT INTERLOCK SOLENOID (ON STEERING COLUMN)
DK BLU WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM PPL
FUSE BLOCK
HOT IN ACC OR RUN
HOT IN START OR RUN
PNK/BLK WIRE
PPL
PPL PPL
TCC/ BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
TRANS FUSE
TURN-B/U FUSE
