GMC Terrain II (2017-2021) lift gate shut face sw led ctrl Wiring diagram
This page shows the only wiring diagram for the component.lift gate shut face sw led ctrl, which is found in the car GMC Terrain II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lift gate shut face sw led ctrl (1 of 1)
BLK WIRE
CENTER CONSOLE COMPARTMENT LAMP
CENTER CONSOLE CUPHOLDER ACCENT LAMP
CHEVROLET
COMPUTER DATA LINES SYSTEM
DRIVER DOOR ACCENT LAMP
DRIVER DOOR HANDLE ACCENT LAMP
FRONT OVERHEAD CONSOLE ASSEMBLY
GMC
GRN/BRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
LEFT REAR DOME/ READING LAMPS
LIFT GATE SHUT FACE SW LED CTRL
LIFTGATE CLOSE SWITCH
LIFTGATE CONTROL MODULE
LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 18
NCA WIRE
PASSENGER DOOR ACCENT LAMP
PASSENGER DOOR HANDLE ACCENT LAMP
RIGHT INSTRUMENT PANEL ACCENT LAMP
RIGHT REAR DOME/ READING LAMPS
W/ INTERIOR LAMP PACKAGE
WHT/BRN WIRE
WHT/YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LIFT GATE SHUT FACE SW LED CTRL
