GMC Terrain I (2009-2015) temp sw Wiring diagrams
This page contains all the electrical diagrams for the component. temp sw, in which he is found in the car GMC Terrain I (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram temp sw (1 of 2)
1 2 3 4 5 6 7 8 9 10 PNK WIRE
11 6 KEY SIGNAL KEY SPLY VOLT
3 2 GREEN LED SIG
BACKUP SPLY
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BREAKOUT)
BRN/WHT WIRE
COMP SW
DISPLAY
DK GRN/WHT WIRE
EMERGENCY IND
EMERGENCY SWITCH
GREEN LED
GROUND BACKUP LMP SPLY VOLT
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN
INSIDE REARVIEW MIRROR
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MIR FUSE
MIRROR DIMMING
ONSTAR IND
ONSTAR SWITCH
PHONE IND
PHONE SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED LED SIG WIRE
RED LED WIRE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (W/ ONSTAR) (CENTER OF DASH)
TEMP SW
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit, without rear view camera -> TEMP SW
Wiring diagram temp sw (2 of 2)
11 6 KEY SIGNAL KEY SPLY VOLT
3 2 GREEN LED SIG
BACKUP SPLY
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BREAKOUT)
BRN/WHT WIRE
CAMERA + SIG CAMERA - SIG
COMP SW
DISPLAY
DK GRN/WHT WIRE
EMERGENCY IND
EMERGENCY SWITCH
GREEN LED
GROUND BACKUP LMP SPLY VOLT
IGN LOGIC
INSIDE REARVIEW MIRROR
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MIRROR DIMMING
NAVIGATION SYSTEM
ONSTAR IND
ONSTAR SWITCH
PHONE IND
PHONE SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED LED SIG WIRE
RED LED WIRE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (W/ ONSTAR) (CENTER OF DASH)
TEMP SW
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit, with rear view camera -> TEMP SW
