GMC Terrain I (2009-2015) (rear bumper harness, 56 cm from Wiring diagrams
This page contains all the electrical diagrams for the component. (rear bumper harness, 56 cm from, in which he is found in the car GMC Terrain I (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram (rear bumper harness, 56 cm from (1 of 2)
BLIND SPOT IND
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
GROUND LED SIGNAL (1) BATT POS VOLT PNK WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF DASH)
LEFT SIDE OBJECT SENSOR MODULE (BEHIND LEFT END OF REAR BUMPER)
NCA WIRE
PASSENGER OUTSIDE REARVIEW MIRROR GLASS PASSENGER OUTSIDE REARVIEW MIRROR
PNK LED SIGNAL (1) BATT POS VOLT WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
RIGHT SIDE OBJECT SENSOR MODULE (BEHIND RIGHT END OF REAR BUMPER)
SERIAL DATA
SERIAL DATA GROUND
URPA MDL FUSE
Go to component -> Blind spot monitoring circuit -> (REAR BUMPER HARNESS, 56 CM FROM
Wiring diagram (rear bumper harness, 56 cm from (2 of 2)
ACTIVE RADIO NOISE CANCELLATION MODULE (W/ ACTIVE NOISE INTERIOR CONTROL)
AUX PWR FRT FUSE
AUX PWR REAR FUSE
BLK WIRE
BODY CONTROL MODULE
CENTER CONSOLE 1 ACCESSORY POWER RECEPTACLE
CENTER CONSOLE 2 ACCESSORY POWER RECEPTACLE
DASH)
DATA LINK CONNECTOR
DK GRN WIRE
DSPLY FUSE
FROM I/P BEC FUSE (DIAGRAM 4 OF 4)
FROM RETAINED ACCESSORY RELAY (DIAGRAM 3 OF 4)
FROM SDM BATT FUSE
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 4)
FRT CAM FUSE
GARAGE DOOR OPENER (IF EQUIPPED)
GROUND DISTRIBUTION SYSTEM
HVAC IGN FUSE IPC IGN FUSE UGDO FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFOTMNT FUSE
INSTRUMENT CLUSTER
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF
INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF DASH)
IOS MDL FUSE
IPC BATT FUSE
LEFT SIDE OBJECT SENSOR MODULE
MULTIMEDIA HVAC CONTROL PLAYER MODULE INTERFACE MODULE (W/ AUDIO INTERFACE)
NCA WIRE
NCM RDO FUSE FUSE
ORG/ WIRE
PASSENGER PRESENCE DETECTION MODULE
PNK WIRE
RADIO/HVAC FRONT VIEW CONTROLS CAMERA MODULE (IF EQUIPPED)
REAR PARKING ASSIST CONTROL MODULE (W/ REAR PARKING ASSIST SENSOR INDICATOR)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RETAINED ACCESSORY POWER RELAY
RIGHT SIDE INFO OBJECT DISPLAY SENSOR MODULE MODULE
RPRNDL FUSE
SDM IGN FUSE
SEAT HEATING CONTROL MODULE
SPARE FUSE
TO INFOTMNT FUSE (DIAGRAM 3 OF 4)
TRANSMISSION SHIFT LEVER POSITION INDICATOR
URPA MDL FUSE
W/ BLIND SPOT MONITORING
W/ NAVIGATION
W/ SPO HEATED SEATS
W/ SPO W/O SPO HEATED HEATED SEATS SEATS
W/O NAVIGATION
W/O SPO HEATED SEATS
Go to component -> Power distribution circuit (3 of 4) -> (REAR BUMPER HARNESS, 56 CM FROM
