GMC Terrain I (2009-2015) fluid pump rly ctrl Wiring diagram

BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) DK GRN WIRE FLUID PUMP RLY CTRL GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT REAR ENGINE COMPT) WPR FUSE LO OFF INT LO OFF INT WIPER SWITCH LOW REF LT BLU WIRE LT GRN WIRE MIST ORG/ WIRE PNK WASHER SW SIG WIRE PNK WIRE PPL REAR WASHER RLY CTRL REAR WINDOW WASHER PUMP RELAY REAR WIPER MOTOR (CENTER OF LIFTGATE) REAR WIPER RELAY REAR WIPER RLY CTRL REAR WIPER SW SIG REAR WIPER/WASHER SWITCH REAR/WPR FUSE RED/WHT WIRE RVC BATT SNSR FUSE TAN WIRE TAN/BLK WIRE WASHER SWITCH WHT WIRE WINDSHIELD WASHER PUMP (WASHER RESERVOIR) WINDSHIELD WASHER PUMP RELAY WINDSHIELD WIPER MOTOR (BELOW LEFT SIDE OF AIR INLET GRILLE) WINDSHIELD WIPER RELAY WINDSHIELD WIPER SPEED CONTROL RELAY WINDSHIELD WIPER/ WASHER SWITCH WIPER MOTOR SW SIG WIPER RLY CTRL WIPER SW HI SIG WIPER SW HIGH SIG WIPER SW LO SIG WSW FUSE YEL WIRE
