GMC Terrain I (2009-2015) driver seat heating switch Wiring diagram
This page shows the only wiring diagram for the component.driver seat heating switch, which is found in the car GMC Terrain I (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat heating switch (1 of 1)
5 6 7 SW SIG HIGH INDICATOR CONTROL LOW INDICATOR CONTROL PPL
AUX PWR FRT FUSE
BACK ELEMENT CTRL
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER BACK HEATING SEAT ELEMENT
DRIVER CUSHION HEATING SEAT ELEMENT
DRIVER HEATED SEAT SWITCH
DRIVER SEAT HEATING SWITCH
GROUND
GRY WIRE
HIGH HEAT IND
HOT W/ ACCESSORY RETAINED POWER RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF DASH)
LOGIC
LOW HEAT IND
LOW REF
MEDIUM HEAT IND
ORG/ WIRE
PASSENGER BACK HEATING SEAT ELEMENT
PASSENGER CUSHION HEATING SEAT ELEMENT
PASSENGER HEATED SEAT SWITCH
POWER DISTRIBUTION SYSTEM
RED WIRE
SEAT HEATING CONTROL MODULE (UNDER DRIVER'S SEAT)
SENS SIG
SPLY VOLT
SUPPLY VOLTAGE
SUPPLY VOLTAGE SW SIG HIGH INDICATOR CONTROL LOW INDICATOR CONTROL
SW SIG HIGH INDICATOR CONTROL LOW INDICATOR CONTROL PPL
YEL WIRE
Go to component -> Heated seats circuit, with spo heated seats -> DRIVER SEAT HEATING SWITCH
