GMC Terrain I (2009-2015) air pump sol fuse wiring diagram
This page shows the only wiring diagram for the component.air pump sol fuse, which is found in the car GMC Terrain I (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
air pump sol fuse wiring diagram (1 of 1)
5-VOLT 1 REF
AIR PUMP FUSE
AIR PUMP SOL FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAM PHASER CTRL
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM FUSE
ENGINE CONTROL MODULE
ENGINE CONTROLS IGNITION RELAY
EXHAUST CAMSHAFT POSITION ACTUATOR SOLENOID VALVE (TOP FRONT OF CYLINDER HEAD)
FUEL INJECTOR 1
FUEL INJECTOR 1 CTRL
FUEL INJECTOR 2
FUEL INJECTOR 2 CTRL
FUEL INJECTOR 3
FUEL INJECTOR 3 CTRL
FUEL INJECTOR 4
FUEL INJECTOR 4 CTRL
GRN WIRE
GRN/GRY WIRE
GROUND
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INTAKE CAMSHAFT POSITION ACTUATOR SOLENOID VALVE (TOP FRONT OF CYLINDER HEAD)
LOW REF
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
ODD IGN FUSE
ORG/ WIRE
PNK/BLK WIRE
PPL
PRE FUSE
SECON- DARY AIR INJECTION PUMP
SECONDARY AIR INJECTION PUMP RELAY
SECONDARY AIR INJECTION SOLENOID VALVE RELAY
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.4l vin k (4 of 5) -> AIR PUMP SOL FUSE
