GMC Terrain I (2009-2015) 1444 1884 pnk 4 9 Wiring diagram

12-VOLT REF CRUISE CTRL SW SIG 1444 1884 PNK 4 9 WIRE 19 1 LOW REF GND 23 24 SERIAL DATA BUS - SERIAL DATA BUS + 7 13 SENS SIG 5-VOLT REF ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRK PEDAL SW SIG BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY CRUISE IND CRUISE SWITCH DATA BUS - DK BLU WIRE DK GRN WIRE ECM BATT FUSE ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) GRY WIRE HI SIG HOT AT ALL TIMES IGN VOLT INSTRUMENT PANEL FUSE BLOCK STR (RIGHT CENTER WHL DM OF DASH) FUSE IPC BATT FUSE LED BACKLIGHT DIMMING CONTROL LEFT STEERING WHEEL CONTROLS SWITCH LO SIG LOGIC INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE PNK WIRE PPL RED/WHT WIRE RESET+ RIGHT STEERING WHEEL CONTROLS SWITCH RVC BATT SNSR FUSE SER DATA SET- STEERING WHEEL AIR BAG COIL (IN STEERING WHEEL) TAN WIRE TAN/BLK WIRE TCM BATT FUSE THROTTLE BODY (2.4L: LEFT SIDE OF ENGINE) (3.6L: TOP RIGHT FRONT OF ENGINE) TRANSMISSION CONTROL MODULE TRANSMISSION INPUT SHAFT SPEED SENSOR TRANSMISSION OUTPUT SHAFT SPEED SENSOR UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE
