Transfer case circuit, k300 only for GMC Suburban K2500 (1985-1999)

4 WHEEL DRIVE LOW (UNDER RIGHT END OF I/P) SIGNAL AUTOMATIC TRANSMISSION ONLY BLK WIRE BRN WIRE CONVENIENCE CENTER (UNDER LEFT SIDE OF I/P) DK BLU WIRE DK GRN WIRE FRONT AXLE ACTUATOR SOLENOID (RIGHT SIDE OF FRONT DRIVE AXLE) FRONT AXLE SOLENOID SWITCH (RIGHT REAR SIDE OF FRONT DRIVE AXLE) FUSE GRY WIRE HOT IN RUN I/P FUSE BLOCK INDICATOR LAMP INSTRUMENT CLUSTER LT BLU WIRE PANEL DIMMER SWITCH (ASSEMBLY) PANEL LPS FUSE PICKUP PNK/WHT WIRE POWERTRAIN CONTROL MODULE PPL PPL PPL RED WIRE RWAL DIODE MODULE (UNDER LEFT SIDE OF I/P) TRANSFER CASE MODE SELECTOR ILLUMINATION LAMP (AT TRANSFER CASE SELECTOR LEVER) TRANSFER CASE RELAY (RIGHT REAR OF ENG COMPT, NEAR BATTERY JUNCTION BLOCK) TRANSFER CASE SWITCH (LEFT TOP OF TRANSFER CASE) TRANSFER CASE SYNCRONIZER
