GMC Suburban K2500 (1985-1999) headlamp, panel dimmer switch Wiring diagram
This page shows the only wiring diagram for the component.headlamp, panel dimmer switch, which is found in the car GMC Suburban K2500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlamp, panel dimmer switch (11 of 11)
BATTERY INPUT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (IN CENTER CONSOLE)
BRN WIRE
CTSY FUSE 3
DK BLU WIRE
GAUGES FUSE 4
GROUND FASTEN BELTS OUT
HEADLAMP, PANEL DIMMER SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (UNDER LEFT SIDE OF DASH)
INSTRU- MENT CLUSTER
KEY-IN WARNING BUZZER SWITCH
LEFT DOOR JAMB SWITCH
LT GRN WIRE
ORG/ WIRE
PKLPS FUSE 9
PNK WIRE
POWER DISTRIBUTION SYSTEM
SAFETY BELTS INDICATOR
SEAT BELT SWITCH (ON DRIVER'S SEAT BELT BUCKLE)
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits, luxury & performance -> HEADLAMP, PANEL DIMMER SWITCH
