Courtesy lamps circuit, without auxiliary lighting for GMC Suburban K1500 (1985-1999)

4-DOOR TRUCKS ONLY BLK WIRE CARGO DOOR JAMB SWITCH (SUBURBAN, TAHOE, YUKON) CTRL CTSY FUSE 3 DOME DEFEAT DOOR JAMB FRONT DOME AND READING LAMP GAGES FUSE 4 GRY WIRE HEADLAMP AND PANEL DIMMER SWITCH DOME LAMP DEFEAT COURTESY LAMPS HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P COMPARTMENT BOX LAMP I/P FUSE BLOCK IGN SW INTERIOR LAMP CONTROL MODULE (UNDER CENTER OF DASH) LAMP OUT LEFT FRONT DOOR JAMB SWITCH LEFT I/P COURTESY LAMP LEFT ILLUMINATED VANITY MIRROR LEFT REAR DOOR JAMB SWITCH MIRRORS SYSTEM NCA WIRE ORG/ WIRE PNK WIRE PPL REAR DOME AND READING LAMP REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND CENTER OF DASH) RIGHT FRONT DOOR JAMB SWITCH RIGHT I/P COURTESY LAMP RIGHT ILLUMINATED VANITY MIRROR RIGHT REAR DOOR JAMB SWITCH UNDERHOOD FUSE-RELAY CENTER HORN FUSE UNDERHOOD LAMP PPL UNDERHOOD REEL LAMP W/ RKE W/O RKE WHT WIRE
