GMC Suburban C2500 (1985-1999) Radio circuits, without amplifier

ANTENNA BARE BLK WIRE BRN WIRE DIESEL GAS DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK LEFT FRONT SPEAKER LEFT FRONT TWEETER LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PPL/WHT WIRE RADIO RADIO BATT FUSE 19 RADIO FUSE 17 REMOTE AUDIO PLAYER RIGHT FRONT SPEAKER RIGHT FRONT TWEETER RIGHT REAR SPEAKER SERIAL DATA VSS SIGNAL RR - RR + LR _ LR + TAN WIRE VEHICLE CONTROL MODULE (LEFT SIDE OF ENGINE COMPARTMENT) VEHICLE SPEED SENSOR BUFFER (BEHIND RIGHT SIDE OF DASH) VSS SIGNAL YEL WIRE
