GMC Suburban C1500 (1985-1999) vehicle speed sensor adaptor Wiring diagram

1-2 SHIFT SOL 1-2 SHIFT SOLENOID 2-3 SHIFT SOL 2-3 SHIFT SOLENOID 3-2 CTRL SOLENOID 3-2 DOWNSHIFT SOL AUTOMATIC TRANSMISSION BATTERY IN BLK WIRE BLK/WHT WIRE BLU WIRE BRAKE FUSE 18 BRAKE SWITCH INPUT BRN WIRE BRN/WHT WIRE DASH FUSE BLOCK DATA CLASS II DK BLU WIRE ECM 1 FUSE ECM-B FUSE ECT SENS INPUT ELECTRONIC BRAKE CONTROL MODULE ENG 1 FUSE ENGINE COOLANT TEMP SENSOR (TOP RIGHT FRONT OF ENGINE) FRONT WHEEL LOCK FUEL PUMP, OIL PRESS SWITCH/ SENDER, FUEL PUMP RELAY GAUGES FUSE 4 GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN OFF, RUN OR START HOT IN RUN HOT IN RUN OR START IGNITION IN INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION INDICATOR LAMP MIL CONTROL ORG/ WIRE PCM GROUND PCS SOL HI OUT PCS SOL LO OUT PNK PNK WIRE PNK WIRE PPL PPL DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) PPL/WHT WIRE PRESS CTRL HI SOLENOID LO RANGE SIGNAL "A" RANGE SIGNAL "B" RANGE SIGNAL "C" RED WIRE RED/BLK WIRE SENSOR GROUND SENSOR RETURN STOPLAMP SWITCH (ON BRAKE PEDAL BRACKET) TAN WIRE TAN/BLK WIRE TCC PWM SOL TCC PWM SOLENOID TCC SOL TCC SOLENOID THROTTLE POSITION SENSOR (MOUNTED TO SIDE OF THROTTLE BODY) TP SENS INPUT TRANS FLUID TEMP SENSOR TRANS FUSE 20 TRANS RANGE PRESSURE SWITCH ASSEMBLY TRANS RANGE SWITCHES TRANS TEMP SIG IN TRANSFER CASE CIRCUIT PNK WIRE TRANSFER CASE, AXLE SWITCHES UNDERHOOD FUSE/RELAY CENTER VEHICLE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR VEHICLE SPEED SENSOR ADAPTOR VSS HI VSS LO WHT WIRE YEL WIRE YEL/BLK WIRE
