Endgate circuit, w/ pubx end enhanced gate for GMC Sierra IV facelift (2022-2024)

AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (+) 5 SERIAL DATA AUXILIARY ENDGATE LIFTGATE EXTERIOR RELEASE SWITCH BATT POS VOLT BLK WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (LEFT END OF DASH) BODY WIRING HARNESS JUNCTION BLOCK COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY GROUND GROUND PICKUP BOX ENDGATE LATCH RELAY HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE LEFT PICKUP BOX AUXILIARY ENDGATE LATCH LH MINOR ENDGATE AJAR SIG LOGIC MINOR ENDGATE HI RLY CTRL MINOR ENDGATE REL SWITCH MINOR ENDGATE REL SWITCH DISCRETE SIGNAL EXTERIOR PICKUP BOX AUXILIARY ENDGATE LATCH RELAY RED/BRN WIRE RED/GRY WIRE RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK RIGHT PICKUP BOX AUXILIARY ENDGATE LATCH SUPPLY VOLTAGE PICKUP BOX ENDGATE LATCH RELAY VIO WIRE WHT WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
