Endgate circuit, w/ powergate for GMC Sierra IV facelift (2022-2024)

AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (+) 4 SERIAL DATA BATT POS VOLT BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (LEFT END OF DASH) BODY WIRING HARNESS JUNCTION BLOCK BRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY ENDGATE LIFTGATE EXTERIOR RELEASE SWITCH ENDGATE RELEASE SW ANALOG SIG INTERIOR ENDGATE RELEASE SW DISCRETE SIG EXTERIOR ENDGATE RELEASE SWITCH GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRY WIRE GRY/BLK WIRE GRY/VIO WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE LEFT PICKUP BOX ENDGATE CINCH LATCH ACTUATOR LIN BUS 1 LOGIC REAR CLOSURE CINCH LATCH MTR 2 CINCH CTRL REAR CLOSURE CINCH LATCH MTR 2 REL CTRL REAR CLOSURE CINCH LATCH MTR CINCH CTRL REAR CLOSURE CINCH LATCH MTR REL CTRL REAR CLOSURE CLUTCH CTRL REAR CLOSURE CLUTCH RETURN REAR CLOSURE LATCH 2 NEUTRAL STATUS SIG REAR CLOSURE LATCH 2 PRIMARY STATUS SIG REAR CLOSURE LATCH 2 SECONDARY STATUS SIG REAR CLOSURE LATCH 2 UNLATCH STATUS SIG REAR CLOSURE LATCH PRIMARY STATUS SIG REAR CLOSURE LATCH SECONDARY STATUS SIG REAR CLOSURE LATCH UNLATCH STATUS REAR CLOSURE NEUTRAL STATUS REAR CLOSURE OBJECT SENS LOW REF REAR CLOSURE OPEN/CLOSE MTR CLOSE CTRL REAR CLOSURE OPEN/CLOSE MTR OPEN CTRL REAR CLOSURE POSITION SENS LOW REF REAR CLOSURE POSITION SENS SIG 1 REAR CLOSURE POSITION SENS SIG 2 REAR CLOSURE POSITION SENS VOLTAGE REF REAR CLOSURE SENS LOW REF 2 REAR GATE MODULE (INSIDE LOWER LEFT SIDE OF ENDGATE) RED/VIO WIRE RIGHT PICKUP BOX ENDGATE CINCH LATCH ACTUATOR VEHICLE STABILITY CONTROL SYSTEM SWITCH VIO/WHT WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE
