Endgate circuit, w/ manual assist power release gate for GMC Sierra IV facelift (2022-2024)

AUTOSAR CAN BUS (+) 5 SERIAL DATA AUXILIARY ENDGATE LIFTGATE EXTERIOR RELEASE SWITCH BATT POS VOLT BLK WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (LEFT END OF DASH) BODY CTRL MODULE LIN BUS 6 BODY WIRING HARNESS JUNCTION BLOCK BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY ENDGATE LIFTGATE EXTERIOR RELEASE SWITCH ENDGATE RELEASE SWITCH GRN WIRE GRN/VIO WIRE GROUND GROUND PICKUP BOX ENDGATE LATCH RELAY GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE LEFT MINOR ENDGATE AJAR SIGNAL LEFT PICKUP BOX AUXILIARY ENDGATE LATCH LEFT PICKUP BOX ENDGATE LATCH LOGIC MAJOR ENDGATE HIGH RELAY CONTROL MAJOR ENDGATE LOW RELAY CONTROL MAJOR ENDGATE REL SW SIG EXTERIOR MAJOR ENDGATE REL SW SIG INTERIOR MINOR ENDGATE REL SW SIG EXTERIOR PICKUP BOX ENDGATE LOCK ACTUATOR RED/BRN WIRE RED/GRY WIRE RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK RIGHT PICKUP BOX ENDGATE LATCH SUPPLY VOLTAGE PICKUP BOX ENDGATE LATCH RELAY VEHICLE STABILITY CONTROL SYSTEM SWITCH W/ ENHANCED ENDGATE W/ STANDARD ENDGATE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
