Heated seats circuit for GMC Sierra IV facelift (2022-2024)

BATT POS VOLT BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE LIN BUS 11 BODY WIRING HARNESS JUNCTION BLOCK BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER FRONT SEAT BACK HEATER DRIVER FRONT SEAT CUSHION HEATER DRV HEATED SEAT THERMISTOR LO REF DRV SEAT BACK HEATING ELEMENT CTRL DRV SEAT BACK HEATING TEMP SNS SIG DRV SEAT BLOWER MOTOR CTRL 1 DRV SEAT HEATING ELEMENT LO REF DRV SEAT HEATING TEMP SNS SIG ENGINE WIRING HARNESS JUNCTION BLOCK FRONT SEAT HEATER VENT CONTROL MODULE (UNDER FRONT PASSENGER SEAT) GRN/VIO WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED NCA WIRE PASS HEATED BACK THERMISTOR LO REF PASS HEATED SEAT THERMISTOR LO REF PASS SEAT BACK HEATING ELEMENT CTRL PASS SEAT BACK HEATING TEMP SNS SIG PASS SEAT BLOWER MOTOR CTRL 1 PASS SEAT HEATING ELEMENT CTRL PASS SEAT HEATING ELEMENT LO REF RED/BRN WIRE RED/GRN WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY WIRE YEL/GRY WIRE

BACK SWITCH BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DOUBLE CAB/ CREW CAB DRIVER BACK DRIVER CUSHION/ DRIVER FRONT SEAT BACK VENTILATION BLOWER DRIVER FRONT SEAT CUSHION VENTILATION BLOWER FRONT HEATER, AIR CONDITIONING USER INTERFACE CONTROL GRN/VIO WIRE GRY/BLK WIRE IND LOGIC MED NCA WIRE PASSENGER PASSENGER BACK PASSENGER CUSHION/ PASSENGER FRONT SEAT BACK HEATER PASSENGER FRONT SEAT BACK VENTILATION BLOWER PASSENGER FRONT SEAT CUSHION HEATER PASSENGER FRONT SEAT CUSHION VENTILATION BLOWER SWITCH VENTILATION VENTILATION SWITCH VIO/WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY WIRE
