Car Wiring Diagrams for Driver"s memory seat circuit for GMC Sierra IV (2018-2022)

BLK/BLU WIRE BLU/GRN WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE DRIVER SEAT MEMORY SWITCH DRIVER SEAT RECLINE MOTOR DRV SEAT RECLINE MOTOR EXIT GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/GRN WIRE HIGH REF (2) HOT AT ALL TIMES LEFT REAR SEAT MOTOR CONTROL LOW REF POSITION SENS SIG POSITIVE VOLT 11 POSITIVE VOLT 50 RED/BRN WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE BLOCK RIGHT REAR SEAT MOTOR CONTROL SEAT FRONT VERTICAL MOTOR POS SENS SIG SEAT FRONT VERTICAL UP SW SIG SEAT FRONT VERTICAL DOWN SW SIG SEAT HORIZONTAL FORWARD SW SIG SEAT HORIZONTAL MOTOR POS SENS SIG SEAT HORIZONTAL REARWARD SW SIG SEAT MEMORY CONTROL MODULE SEAT REAR VERTICAL DOWN SW SIG SEAT REAR VERTICAL UP SW SIG SEAT RECLINE FORWARD SW SIG SEAT RECLINE REARWARD SW SIG SET SIG SET- SWITCH SIG 1 WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE

BLK WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER LEFT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER RIGHT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT FRONT VERTICAL MOTOR DRIVER SEAT HORIZONTAL MOTOR DRIVER SEAT REAR VERTICAL MOTOR FORWARD CTRL FRT VERT MOTOR DOWN CTRL FRT VERT MOTOR UP CTRL GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE LIN BUS 1 LOW SPD GMLAN MOTOR FORWARD CTRL MOTOR REARWARD CTRL NCA WIRE REARWARD CTRL RR VERT MOTOR DOWN CTRL RR VERT MOTOR UP CTRL SEAT MEMORY CONTROL MODULE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE
