Car Wiring Diagrams for Head-up display circuit for GMC Sierra IV (2018-2022)

BATT POS VOLT BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BRN/BLU WIRE BUS 7 (-) CABLE) COMPUTER DATA LINES SYSTEM GRN/BLK WIRE GRY/GRN WIRE GY LVDS SIGNALING CABLE HEAD-UP DISPLAY HEAD-UP DISPLAY SWITCH HEADLAMP ON HOT AT ALL TIMES HUD HUD SW LOW REF HUD SW SIG INFO LIN BUS 1 LOGIC INSTRUMENT CLUSTER LVDS RED/WHT WIRE RIGHT INSTRUMENT PANEL FUSE BLOCK SER DATA (+) 2 SIGNALING WHT WIRE YEL WIRE YEL/WHT WIRE
