GMC Sierra IV (2018-2022) solenoid low side control wiring diagram
This page shows the only wiring diagram for the component.solenoid low side control, which is found in the car GMC Sierra IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
solenoid low side control wiring diagram (1 of 1)
2.7L TURBO
3.0L TURBO DIESEL
5.3L
ACCESSORY WAKEUP SERIAL DATA
AUTO SWITCH
BATT POS VOLT
BLK/BRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH A CTRL
CLUTCH B CTRL
CLUTCH C CTRL
CLUTCH SOLENOID CTRL
COMPUTER DATA LINES SYSTEM
DRIVE MODE SELECT SWITCH
ENGINE CONTROL MODULE
ENGINE CONTROLS SYSTEM
GMLAN SERIAL DATA (-) (1) (PINS: 39 TO 46 NOT USED)
GMLAN SERIAL DATA (-) (1) (PINS: 55 TO 58 NOT USED) 59
GMLAN SERIAL DATA - 1
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INPUT SPD SIG
LEFT SWITCH
LOW REF 3
OUTPUT SPD SIG
POWER DISTRIBUTION SYSTEM
RED/GRN WIRE
RIGHT INSTRUMENT PANEL FUSE BLOCK
RIGHT SWITCH
RUN/CRANK IGNITION 1 VOLT
SERIAL DATA (-) (1)
SIG GROUND
SNOW SWITCH
SOLENOID LOW SIDE CONTROL
SPORT SWITCH
SWITCH SIG
TCC ON/OFF SOLENOID A CTRL
TCC ON/OFF SOLENOID B CTRL
TRANS CLUTCH G CTRL
TRANS CLUTCH H CTRL
TRANS HI SIDE DRIVER 1 SIG
TRANS HI SIDE DRIVER 2 SIG
TRANS INTERMEDIATE SPD SIG
TRANS MAIN LINE PRESSURE SOLENOID CTRL (PINS: 4 TO 6 NOT USED) 7
TRANS OIL TEMP SENS LO REF (PINS: 29 TO 32 NOT USED)
TRANS OIL TEMP SENS SIG
TRANS SENS A 9 VOLT REF (PINS: 9 TO 12 NOT USED) 13
TRANS SENS B 9 VOLT REF
TRANSMISSION CONTROL MODULE (BEHIND LEFT CORNER OF THE RADIATOR)
UNDERHOOD FUSE BLOCK
VIO/BLK WIRE
VIO/WHT WIRE
VIO/YEL WIRE
VOLT REF (1)
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> A/t circuit, 8 speed (1 of 3) -> SOLENOID LOW SIDE CONTROL
