GMC Sierra IV (2018-2022) dome/reading lp disable sw sig Wiring diagram
This page shows the only wiring diagram for the component.dome/reading lp disable sw sig, which is found in the car GMC Sierra IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dome/reading lp disable sw sig (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
COURTESY LP SW SIG
DOME/READING LP CONTROL
DOME/READING LP DISABLE SW SIG
DOUBLE, CREW CAB
DRIVER DOOR HANDLE FLOOD LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER WINDOW MOTOR LOGIC
FRONT OVERHEAD CONSOLE ASSEMBLY
FRT FOOTWELL ACCENT LIGHTING CONTROL
GND 11
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
INADVERTENT LOAD CTRL
INTR DOOR HANDLE ACCENT LIGHTING CTRL
LF DR AJAR SW SIG
LOGIC
NCA WIRE
PASSENGER DOOR HANDLE FLOOD LAMP
PNK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RF DR AJAR SW SIG
RIGHT INSTRUMENT PANEL FUSE BLOCK
SECONDARY FUSED BATT POSITIVE VOLTAGE 34
SECONDARY FUSED BATT POSITIVE VOLTAGE 51
VIO/GRN WIRE
W/ FORWARD COLLISION ALERT, FULL VIDEO DISPLAY MIRROR
W/ POWER OPERATED, EXPRESS UP/DOWN
W/O FORWARD COLLISION ALERT, FULL VIDEO DISPLAY MIRROR
W/O POWER OPERATED, EXPRESS UP/DOWN
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> DOME/READING LP DISABLE SW SIG
