GMC Sierra IV (2018-2022) am/fm ant sig coax bk Wiring diagram
This page shows the only wiring diagram for the component.am/fm ant sig coax bk, which is found in the car GMC Sierra IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram am/fm ant sig coax bk (1 of 1)
AM/FM ANT SIG COAX BK
BACK
BACK- WARD
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
COAX
COAX BU GPS
COAX OG COAX CAM SIG
COMPUTER DATA LINES SYSTEM
DOWN
FORWARD/
GRY/BRN WIRE
HOME
INFO DISPLAY MODULE
LOGIC
LVDS
MUTE
NAVIGATION ANTENNA
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
RADIO
RADIO ANTENNA
RADIO PRESETS STEERING WHEEL CONTROLS SWITCH
RADIO VOLUME STEERING WHEEL CONTROLS SWITCH
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT MOBILE TELEPHONE MICROPHONE
RIGHT STEERING WHEEL CONTROLS SWITCH
SEEK LEFT UP
SEEK RIGHT SELECT
VIO/YEL WIRE
VOICE
W/O ONSTAR
WHT/YEL WIRE
WIR BG
WLAN WIRELESS COMMUNICATION ANTENNA
YEL/BLU WIRE
Go to component -> Navigation circuit, w/o amplifier (3 of 3) -> AM/FM ANT SIG COAX BK
