Shift interlock circuit for GMC Sierra III facelift (2015-2018)

5 VOLT REF 6.2L BASE EQUIPMENT EXCEPT BASE EQUIPMENT BCM 6 FUSE BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DATA BUS 1 DK BLU WIRE DLIS FUSE GMLAN SERIAL GRY/RED WIRE HI SPEED HI SPEED GMLAN SERIAL DATA (-) 1 HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT PANEL JUNCTION BLOCK KEY-IN SWITCH LEFT INSTRUMENT PANEL FUSE BLOCK LOW REF OFF OFF RUN/CRANK VOLT PPL/BLK WIRE RED/BLU WIRE RED/DK BLU WIRE RED/WHT WIRE RIGHT INSTRUMENT PANEL FUSE BLOCK RUN WIRE SENS LOW REF SERIAL DATA BUS (-) IMS MODE SW RETURN SERIAL DATA BUS- SHIFT INTERLOCK SOL CTRL STOP LAMP SW SIG TRANSMISSION CONTROL MODULE TRANSMISSION FLUID PRESSURE SWITCH TRANSMISSION INTERNAL MODE SWITCH AUTOMATIC TRANSMISSION ASSEMBLY TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR WHT WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE YEL/WHT WIRE

4.3L/ 5.3L 6.2L 6.6L 6.0L 6.2L, 6.6L 4.3L, 5.3L, 6.0L AUTOMATIC TRANSMISSION ASSEMBLY (4.3L, 5.3L, 6.0L) BLK/BRN WIRE BLK/GRN WIRE BLU/YEL WIRE BPP SENS LO REF BPP SENS SIG BRAKE PEDAL POSITION SENSOR (BEHIND BRAKE PEDAL ASSEMBLY) COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DK BLU/YEL WIRE ENGINE CONTROL MODULE EXCEPT BASE EQUIPMENT GMLAN DATA BUS (+) 1 GRY WIRE GRY/RED WIRE INSTRUMENT PANEL JUNCTION BLOCK PARK/NEUTRAL SIG TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH WHT WIRE WHT/GRN WIRE WHT/GRY WIRE
