GMC Sierra III facelift (2015-2018) reductant injector Wiring diagram
This page shows the only wiring diagram for the component.reductant injector, which is found in the car GMC Sierra III facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reductant injector (1 of 1)
BATTERY FUSE BLOCK
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/LT GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CHARGE AIR COOLER OUTLET TEMPERATURE SENSOR
COMPUTER DATA LINES SYSTEM
CTRL
DK BLU/GRY WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
ENGINE OIL PRESSURE IND
EXHAUST TEMPERATURE SENSOR 1
EXHAUST TEMPERATURE SENSOR 2
EXHAUST TEMPERATURE SENSOR 3
EXHAUST TEMPERATURE SENSOR 4
EXHAUST TEMPERATURE SENSOR 5
FUEL GAUGE IND
FUSE 3
GRN/BRN WIRE
GRN/GRY WIRE
GRY/GRN WIRE
GRY/LT GRN WIRE
HOT AT ALL TIMES
IND CTRL
INSTRUMENT CLUSTER
LO SPD GMLAN
LOGIC
LOW CONTROL
LOW REFERENCE
LT GRN/BRN WIRE
LT GRN/LT BLU WIRE
MALFUNCTION INDICATOR LAMP
NCA WIRE
RED/VIO WIRE
REDUCTANT INJECTOR
RELAY CTRL
SHUTDOWN SIGNAL
TRANSMISSIONS SYSTEM
VALVE HIGH CTRL
VIO/BRN WIRE
VIO/GRN WIRE
VIO/LT BLU WIRE
VIO/LT GRN WIRE
WAIT TO START IND
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/DK BLU WIRE
Go to component -> Wiring diagram engine performance 6.6l vin y (4 of 9) -> REDUCTANT INJECTOR
