GMC Sierra Classic 2500 HD (2007-2007) windshield washer switch signal Wiring diagram
This page shows the only wiring diagram for the component.windshield washer switch signal, which is found in the car GMC Sierra Classic 2500 HD (2007-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield washer switch signal (1 of 1)
ACCESSORY VOLTAGE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
CHECK WASHER FLUID
DK BLU WIRE
GROUND LSD
HI LO
HOT AT ALL TIMES
HOT IN RUN AND ACC
I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
INSTRUMENT PANEL CLUSTER
LO OFF PULSE
LOW WASHER FLUID IND SIG
MESSAGE CENTER
MIST HI
MIST WASH
OFF
ORG/ WIRE
PNK WIRE
RED WIRE
SERIAL DATA
TAN WIRE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPT)
W/S WASH FUSE
W/S WASH RELAY
W/S WIPER FUSE
WASHER FLUID LEVEL SENSOR (IN WASHER FLUID RESERVOIR) (EXCEPT 4.3L BASE)
WHT WIRE
WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR)
WINDSHIELD WASHER RELAY CNTRL
WINDSHIELD WASHER SWITCH SIGNAL
WINDSHIELD WIPER HIGH SIGNAL
WINDSHIELD WIPER MOTOR MODULE (UNDER WINDSHIELD COWL, BETWEEN WIPER ARMS)
WINDSHIELD WIPER MOTOR PARK SIGNAL
WINDSHIELD WIPER/ WASHER SWITCH
YEL WIRE
