Wiring diagram engine performance 6.6l vin 1s, except california (2 of 4) for GMC Sierra 3500 (2002-2006)

20 SERIES 30 SERIES ACCELERATOR PEDAL POSITION SENSOR (BEHIND ACCELERATOR PEDAL) BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CAMSHAFT POSITION SENSOR (FRONT OF ENGINE) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ECMB FUSE ECMPRV FUSE FUEL PUMP (AUXILIARY TANK (LEFT SIDE FRAME RAIL) FUEL PUMP RELAY FUSE HOLDER GLOW PLUG RELAY GLOW PLUG/ INTAKE HEATER RELAY ASSEMBLY GLOW PLUGS GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES BATTERY FUSE HOT IN RUN, START UNDER- HOOD FUSE BLOCK FUEL HT FUSE IGN 1 RELAY INTAKE AIR HEATER (REAR OF ENGINE) INTAKE AIR HEATER RELAY INTAKE AIR TEMPERATURE/ MASS AIRFLOW SENSOR (IN AIR INDUCTION TUBE) LT BLU WIRE LT BLU/BLK WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PNK/YEL WIRE PPL PPL 28 29 RED WIRE RED/BLK WIRE TAN WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
