6.0l vin k, a/t circuit for GMC Sierra 2500 HD (2002-2012)

AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR SIGNAL AUX HVAC- IGN FUSE 45 BATT + GND BRAKE PEDAL SIG BLK/WHT WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) FUSE 19 GROUND DISTRIBUTION SYSTEM HOT AT ALL TIMES HOT W/ RUN/CRNK RELAY ENERGIZED IGN INSTRUMENT CLUSTER PANEL (IPC) LEFT I/P JUNCTION BLOCK LOGIC LOW REFERENCE LT BLU/WHT WIRE LT GRN/BLK WIRE MISC-IGN FUSE 43 ORG/BLK WIRE PC SOLENOID 1 CONTROL PC SOLENOID 2 CONTROL PC SOLENOID 3 CONTROL PC SOLENOID 4 CONTROL PC SOLENOID 5 CONTROL PNK IGN WIRE PNK PNK ANTI-LOCK BRAKES SYSTEM WIRE PNK PNK PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL/WHT WIRE PRESSURE CONTROL (PC) SOLENOID VALVE 1 PRESSURE CONTROL (PC) SOLENOID VALVE 2 PRESSURE CONTROL (PC) SOLENOID VALVE 3 PRESSURE CONTROL (PC) SOLENOID VALVE 4 PRESSURE CONTROL (PC) SOLENOID VALVE 5 RED/WHT WIRE REPLICATED TOS SIGNAL SHIFT SOLENOID (SS) 1 CONTROL SHIFT SOLENOID (SS) 2 CONTROL SHIFT SOLENOID (SS) VALVE 1 SHIFT SOLENOID (SS) VALVE 2 STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCM- BATT FUSE 14 TO AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) (DIAGRAM 2 OF 2) TORQUE CONVERTER CLUTCH (TCC) PRESSURE CONTROL (PC) SOLENOID VALVE TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL TOW/ HAUL IND TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON TRANSFER CASE TAILSHAFT HOUSING) VSS SIG W/0 2 SPEED TRANSFER CASE

A/T MANUAL SHIFT SWITCH AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION FLUID PRESSURE (TFP) MANUAL VALVE POSITION SWITCH AUTOMATIC TRANSMISSION INPUT SHAFT SPEED (ISS) AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) AUTOMATIC TRANSMISSION OUTPUT SHAFT SPEED (ISS) AUTOMATIC TRANSMISSION SHIFT LEVER BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DK BLU WIRE FROM AUTOMATIC TRANSMISSION (DIAGRAM 1 OF 2) FTP SWITCH 1 VOLTAGE FTP SWITCH 3 VOLTAGE FTP SWITCH 4 VOLTAGE FTP SWITCH 5 VOLTAGE GMLAN GMLAN SERIAL SERIAL DATA DATA BUS - BUS + GMLAN SERIAL DATA BUS + GRN WIRE GRY WIRE INPUT SPEED SENSOR (ISS) SIGNAL ISS/OSS SUPPLY VOLTAGE LT BLU WIRE NCA WIRE OUTPUT SPEED SENSOR (OSS) SIGNAL PNK WIRE PPL RED WIRE REF SENSOR TAN WIRE TAN/BLK WIRE TAP TOW/ UP/ HAUL TAP SW DOWN SIG SW SIG TOW/ HAUL SWITCH TRANSMISSION CONTROL MODULE (TCM) CONTROL SOLENOID VALVE ASSEMBLY TRANSMISSION RANGE SWITCH SIG A TRANSMISSION RANGE SWITCH SIG B TRANSMISSION RANGE SWITCH SIG C TRANSMISSION RANGE SWITCH SIG P VOLT W/ ELECTRONIC STEERING CONTROL W/O 2 SPEED TRANSFER CASE WHT WIRE YEL WIRE
