Power door locks circuit, base package for GMC Sierra 2500 HD (2002-2012)

11 12 UNLCK SIG LCK SIG 3 10 B+ GMLAN 7 9 6 LCK CNTRL UNLCK CNTRL UNLCK CNTRL 9 18 UNLCK SIG LCK SIG BLK WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CREW CAB DIM FUSE BCM FUSE DK BLU WIRE DK GRN WIRE DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR LOCK SWITCH DVR UNLCK FUSE GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE OF DASH, LCK 1 FUSE LCK 2 FUSE LEFT REAR DOOR LATCH ASSEMBLY LOCK ACTUATOR LOCK PCB RELAY LT BLU WIRE ORG/BLK WIRE PASSENGER DOOR LATCH ASSEMBLY PASSENGER DOOR LOCK SWITCH PNK/BLK WIRE RED/WHT WIRE RIGHT I/P JUNCTION BLOCK (IN RIGHT END OF DASH) RIGHT REAR DOOR LATCH ASSEMBLY TAN WIRE UNLCK 1 FUSE UNLCK 2 FUSE UNLOCK PCB RELAY W/ CONVENIENCE PACKAGE W/O CONVENIENCE PACKAGE WHT WIRE
